Eaton Moeller 239404 DILM80 400v 50hz 37kw 3pole Contactor
Part No.:
Eaton Moeller xStart 239404 DILM80 400v 50hz 37kw DIN rail mounting 3 pole Contactor accepts top and side mounting auxilliaries contacts
AC1 rating free air thermal current - 90amp
AC3 rated operational current 380/440v - 80amp
Used for Single or Three phase AC3 motor loads or AC1 resistive Lighting or Heating Loads
NEMA size 3
Dimensions H. 170mm x W. 90mm without side auxiliaries (with 1 side auxiliary on each side 111mm x 160mm Stand off front to back without Front mounting auxiliary(with Auxiliary 175mm from base to top of auxiliary)
Catalogue No1: DILM80 (400V50hz)
Catalogue No2: 239404
