Jayflame 2.5mm 2 Core + Earth White Fire Resistant Cable - 100m Coil
Part No.:
Every Reel of Jayflame fire performance cable has individual cores that are tested during manufacture and issued with a test pass number, also benefitting from an issue of a unique sequential batch number. Designed and manufactured with the installer in mind simple to strip and safe to dress and handle. Also this cable is is easy to prepare for termination with no troublesome multiple sheaths to strip, jayflame has a superb working flexibilty providing reduced installation times and Costs.
Features -
- Conductor Construction - 2 x 2.5mm Class 1 Soild Plain Annealed Copper
- CPC (Eath) Construction - Tinned Annealed Copper
- Core Insulation Construction - Fire Retardant Silicon
- Screening Construction - Aluminium Foil
- Outer Sheath Construction - White Low Smoke Zero Halogen
- Working Voltage Core To Core - 500 Volts
- Working Voltage CPC to Core - 300 Volts
- Minimum Bending Radius - 6 x Diameter
- Operating temperature Range - -40oC to +90oC
- LPCB & BASEC Approved to the relevant standard
- Current Rating - 27 Amps (Clipped Direct) 23 Amps (Enclosed)
- Approxiamte cable Diameter - 9.0mm
- Weight - 14.1 kg's/100 Metre Coil
- 10 Year Warranty
