Manrose LT12S 12v standard transformer for 150mm SELV
Part No.:
Standard model for remote switching
Designed to power 12V low voltage fans installed in the splash area of the shower or bath, the LT12 series of Safety Extra Low Voltage (SELV) transformers can be mounted in the loft area (not Pullcord, Humidistat or PIR models) or high-up on the ceiling next to the pullcord light switch.
LT 35watt models are for use with 150 Range Such as
XF150BLV & XF150ALV - WF150BLV & WF150ALV & CF200LV Centrifugal Fan
Electrical Input 220-240V - 50Hz . Output 12volt AC. 50Hz 35VA S.E.L.V. on LT Series. Must be mounted out of reach of the person using the bath or shower. These appliances are double insulated and do not require an earth, but must be connected to the supply through a suitable double pole isolating switch with a minimum contact gap of 3mm on fixed wiring circuits. The protective fuse must not exceed 3A and installation must be supervised by a qualified electrician. See zone diagram for transformer zone rating.
Size L.145mm x H.82mm x D.78mm
